Copper tube in roll
Specific for air conditioning systems and the transport of refrigerant gases
| sku | model | price | info | add to cart | |
|---|---|---|---|---|---|
|
|
00000011120 |
COPPER PIPE L.W.C - 1/4" - thk./Cu 0,80 mm - thk./insulation 6 mm |
on request |
Physical data UM Base: Dimension: Volume: Weight: Minimum Order Quantity: Customs data Customs Code |
Info Request |
|
|
00000011121 |
COPPER PIPE L.W.C - 3/8" - thk./Cu 0,80 mm - thk./insulation 6 mm |
on request |
Physical data UM Base: Dimension: Volume: Weight: Minimum Order Quantity: Customs data Customs Code |
Info Request |
|
|
00000011122 |
COPPER PIPE L.W.C - 1/2" - thk./Cu 1,00 mm - thk./insulation 10 mm |
on request |
Physical data UM Base: Dimension: Volume: Weight: Minimum Order Quantity: Customs data Customs Code |
Info Request |
|
|
00000011123 |
COPPER PIPE L.W.C - 1/2" - thk./Cu 0,80 mm - thk./insulation 6 mm |
on request |
Physical data UM Base: Dimension: Volume: Weight: Minimum Order Quantity: Customs data Customs Code |
Info Request |
|
|
00000011124 |
COPPER PIPE L.W.C - 5/8" - thk./Cu 1,00 mm - thk./insulation 10 mm |
on request |
Physical data UM Base: Dimension: Volume: Weight: Minimum Order Quantity: Customs data Customs Code |
Info Request |
|
|
00000011125 |
COPPER PIPE L.W.C - 3/4" - thk./Cu 1,00 mm - thk./insulation 10 mm |
on request |
Physical data UM Base: Dimension: Volume: Weight: Minimum Order Quantity: Customs data Customs Code |
Info Request |
|
|
00000011128 |
COPPER PIPE L.W.C - 7/8" - thk./Cu 1,00 mm - thk./insulation 10 mm |
on request |
Physical data UM Base: Dimension: Volume: Weight: Minimum Order Quantity: Customs data Customs Code |
Info Request |
|
|
000011120/1 |
COPPER PIPE L.W.C - 1/4" - thk./Cu 1,00 mm - thk./insulation 6 mm |
on request |
Physical data UM Base: Dimension: Volume: Weight: Minimum Order Quantity: Customs data Customs Code |
Info Request |
|
|
000011121/1 |
COPPER PIPE L.W.C - 3/8" - thk./Cu 1,00 mm - thk./insulation 6 mm |
on request |
Physical data UM Base: Dimension: Volume: Weight: Minimum Order Quantity: Customs data Customs Code |
Info Request |
Product informations
Copper pipe specifically for air conditioning systems and the transport of refrigerant gases; the pipe is sold in coils, with the copper diameter expressed in inches as per EN 12735-1.
Product features
- each roll is stapled at the end to keep its inner surface clean
- the insulation material is extruded polyethylene foam
- LDPE (low-density polyethylene) inner sheath with high mechanical strength
- tubing is available in thicknesses: 0.8 mm and 1 mm
Technical Features
| MATERIAL | ACR Cu-DHP 99 min seamless annealed without welding |
|---|---|
| FIRE BEHAVIOUR | insulation material BL-s1-d0 |
| RESISTANCE | water vapor diffusion resistance factor (anti-condensation) > 15000 mm/mK |
| THERMAL CONDUCTIVITY | 40°C ≤ 0,40 |
| TEMPERATURE OF USE | - 80°C ÷ + 100°C |
| PIPE SKU | DIMENSIONS | LENGTH | COPPER THICKNESS | THK./INSULATION | MAXIMUM PRESSURE |
|---|---|---|---|---|---|
| 11120 | 1/4" - 6.35 mm | 50 m | 0,80 mm | 6 mm | 130 bar |
| 11121 | 3/8" - 9.52 mm | 50 m | 0,80 mm | 6 mm | 87 bar |
| 11123 | 1/2" - 12.70 mm | 50 m | 0,80 mm | 6 mm | 80 bar |
| 11120/1 | 1/4" - 6.35 mm | 50 m | 1,00 mm | 6 mm | 150 bar |
| 11121/1 | 3/8" - 9.52 mm | 50 m | 1,00 mm | 6 mm | 100 bar |
| 11122 | 1/2" - 12.70 mm | 25 m | 1,00 mm | 10 mm | 80 bar |
| 11124 | 5/8" - 15.87 mmv | 25 m | 1,00 mm | 10 mm | 63 bar |
| 11125 | 3/4" - 19.05 mm | 25 m | 1,00 mm | 10 mm | 58 bar |
| 11128 | 7/8" - 22.22 mm | 25 m | 1,00 mm | 10 mm | 50 bar |
