Electronic Manometer
Model MP2101
FOR SPECIFIC INFORMATION DEDICATED TO THE PRODUCT, CONTACT OUR TECHNICAL DEPARTMENT
BUILT IN ACCORDANCE WITH EMC 2004/108/EC AND EN 61010-1 DIRECTIVES
| sku | model | price | info | add to cart | |
|---|---|---|---|---|---|
|
|
00000090014 |
MULTIFUNCTIONAL PRESSURE GAUGE - MP210I |
€2.584,90 Excl. Taxes |
Physical data UM Base: Dimension: Volume: Weight: Minimum Order Quantity: Customs data Customs Code |
Info Request |
Product informations
New pressure gauge for measuring pressure up to 1 bar (with MPR 10000 sensors), suitable for measuring gases and liquids; this instrument can print the measured values and store them for transfer to PC. Equipped with internal software for testing the UNI 7129 gas system (with supplied external pump) and UNI 11173:2012; it is also possible to measure the draft in accordance with the UNI 10845 standard correlated to 20°C.
Product features
- measures pressure, air velocity, air flow, temperature, velocity, gas leaks and carbon monoxide
- interchangeable modules
- 2 Pt100 temperature inputs
- up to 6 simultaneous measurements
- large graphic display
- calibration report
The kit includes
- transport case
- terminal in stainless steel Ø 6 x 100 mm
- charger
- USB cable
- calibration report
- infrared printer (with 4 batteries and spare paper included)
- mini-DIN cable for probe
- KEG-3 system seal kit
- pressure modules MPR 10000 and MPR 500
- silicone pipe Ø 4 x 7 mm
- crystal pipe Ø 4 x 6 mm
Probes available (ONLY ON REQUEST)
- temperature probe
- CO/temperature probe
- gas leak probe
- optical/contact tachometric probe
Technical Features
| MEASUREMENT RANGE |
|
|---|---|
| RESOLUTION |
|
| MEASUREMENT ACCURACY |
|
| UNIT |
|
| DISPLAY | touch screen |
| INTERFACE | USB / IR |
| POWER SUPPLY | Li-Ion 4,8 V, 1500 m/Ah |
| DIMENSIONS | 104 x 204 x 63 mm (WxHxD) |
| WEIGHT | 485 g |
| WORKING TEMPERATURE | 0°C ÷ + 50°C |
| DEGREE OF PROTECTION | IP54 (protected against splashing water from any direction and protected against dust, such as not to affect the operation of the device) |
| OVERPRESSURE ALLOWED |
|
